85 Ton Vertical Injection Molding Machine With Rotary Table For Plastic Toys
The 85 Ton Vertical Injection Molding Machine With Rotary Table For Plastic Toys is one of our premier products as a professional manufacturer of vertical injection molding machines with 17 years of manufacturing experience. This machine is specifically designed for the production of plastic toys and offers a range of innovative features.
Our machines are widely applied in the field of injection overmoulding, multi-colors injection moulding, multi-componentsinjection moulding, high-precision injectionmoulding, thermosetting injection moulding and liquid siliconeinjection moulding etc.
We can customize and develop according to the actual needs of customers and provide the most precise, efficient and economical personalized combination solution.
Specifications:
| ITEMS |
UNIT |
TFV3-85R2 |
| Injection Unit |
Shooter configuration code |
name |
Z8 |
| Screw stroke |
mm |
140 |
| Screw Diameter |
mm |
32 |
36 |
40 |
| Theoretical Injection Volume |
cm3 |
113 |
143 |
176 |
| Injection Weight(PS) |
g |
105 |
133 |
164 |
| oz |
3.69 |
4.67 |
5.77 |
| Screw Speed Rotation |
r.p.m |
10~280 |
| Positioning ring diameter |
mm |
120 |
| Claping Unit |
Clamping Force |
KN(ton) |
833(85)/980(100) |
| Clamping Stroke |
mm |
250 |
| Top bar spacing |
mm |
80 |
| Ejector Distance |
mm |
100 |
| Ejector Force |
KN(ton) |
45(4.6) |
| Others |
System Pressure |
Mpa(kgf/cm2) |
13.7(140)/17.2(175) |
| Electric Power |
KW |
15+2.2/18+2.2 |
| Heater Power |
KW |
7 |
| Machine Dimensions |
L*W*H |
m |
2.3*1.8*2.7 |
| Machine Weight |
ton |
4.6 |
Features:
- vertical clamping mold, vertical injection
- Automatic insertion and extraction equipment can be installed to achieve fully automated production
- Easy to operate, high production efficiency
Machine Pictures:
Applications:
FAQ:
Q1: Are you a trading company or manufacturer?
A: We are a factory located in Dongguan city-the largest industrial manufacturing area in China. All the machines are manufactured by our own employees in our own factory.
Q2: Do you test all goods before delivery?
Yes, we have 100% testing before delivery
Q3:How do you handle packaging and shipping?
A: Our spool are plastic-lined inside and packaged in cartons for safe transportation.However,we can also customize the packaging according to your specific requirements.
Q4: How do you calculate tonnage for injection molding?
A: Tonnage = Volume * Maximum Safety Pressure
Therefore, it is always best to consult with an experienced injection molders to determine the exact tonnage in injection required for a specific application. Normally, 5 tons per square inch is used for calculating the clamping tonnage for any given mould.
Q5: How about your delivery time?
A:Generally speaking, it will take 20 to 45 days after receiving the advance payment. The specific delivery time depends on
Regarding your order and quantity.
